10 Ton Diesel Forklift
Extra-heavy-duty 10-ton diesel forklift with 3,000 mm lift height and strong hydraulic drive for large and demanding industrial loads.
3,500 kg
Rated Capacity
3,000 mm
Standard Lift Height
Xinchai / Optional
Engine
Request a Quote
Features
Rated capacity of 10,000 kg at a 600 mm load center for extra-heavy industrial material handling.
Standard 3-meter mast with a full-load lifting speed of up to 310 mm/s; custom lift heights are available on request.
Hydraulic transmission and an 85 kW Quanchai high-pressure common-rail engine provide dependable power for large loads.
4,000 mm minimum turning radius and 250 mm ground clearance support stable operation in ports, heavy-industry yards, factories, and large logistics sites.
Video
Specs & Compare
| Rated Capacity | 10,000 kg | Types of fuel | Diesel |
| Load Center | 600 mm | Engine Power | 85 kW |
| Standard Mast | 3,000 mm | Optional Lift Height | Up to 3–6 m |
| Fork Length | 1,220 mm / Optional | Transmission | Hydraulic / Mechanical |
| Travel Speed | 16 / 22 km/h | Lift Speed | 310 mm/s |
| Gradeability | 19% / 20% | Turning Radius | 4,000 mm |
| Overall Width | 2,275 mm | Overall Length | 5,500 mm |
| Machine Weight | 12,510 kg | Tire Type | Pneumatic / Optional Solid |
| Optional Functions | Side Shift / Fork Positioner | Color & Logo | Custom Available |
| Export Support | EXW / FOB / CIF | Documents | CE / Manual / Packing List |
