CPC60
6 Ton Diesel Forklift
Powerful 6-ton diesel forklift with 3,000 mm lift height, hydraulic transmission, and durable performance for heavy industrial handling.
3,500 kg
Rated Capacity
3,000 mm
Standard Lift Height
Xinchai / Optional
Engine
Request a Quote
Features
Rated capacity of 6,000 kg at a 600 mm load center for heavy industrial loads.
Standard 3-meter mast with a full-load lifting speed of up to 470 mm/s; custom lift heights are available on request.
Hydraulic transmission and an 85 kW Quanchai high-pressure common-rail engine deliver dependable heavy-duty performance.
3,430 mm minimum turning radius and 230 mm ground clearance provide stable handling for warehouses, factories, ports, and yards.
Video
Specs & Compare
| Rated Capacity | 6,000 kg | Types of fuel | Diesel |
| Load Center | 600 mm | Engine Power | 85 kW |
| Standard Mast | 3,000 mm | Optional Lift Height | Up to 3–6 m |
| Fork Length | 1,220 mm / Optional | Transmission | Hydraulic / Mechanical |
| Travel Speed | Up to 23 km/h | Lift Speed | 470 mm/s |
| Gradeability | 20% / 25% | Turning Radius | 3,430 mm |
| Overall Width | 1,995 mm | Overall Length | 4,750 mm |
| Machine Weight | 8,640 kg | Tire Type | Pneumatic / Optional Solid |
| Optional Functions | Side Shift / Fork Positioner | Color & Logo | Custom Available |
| Export Support | EXW / FOB / CIF | Documents | CE / Manual / Packing List |
