Minimum turning radius:2800mm
Wheelbase:2560mm
Hydraulic power steering
Demande de devis
Configuration
Caractéristiques
The center of gravity of the whole vehicle is lowered, and the high-position carrying capacity is stronger than that of a forklift of the same tonnage. The high-strength overall chassis structure greatly increases the durability of the forklift and prolon
Good stability, low center of gravity when turning.
It has the function of standing slope, low noise, flexible operation and low maintenance cost.
Equipped with a priority valve, in the case of insufficient power, it will give priority to action and steering when tilting, lifting and steering.
Vidéo
Spécifications et comparaison
| Capacité de charge | 7000 kg |
| Longueur (sans fourches) | 3600mm |
| Largeur | 1860mm |
| Hauteur (protection du toit) | 2260mm |
| Hauteur de levage | 3000mm (personnalisable) |
| Vitesse maximale de fonctionnement à vide (réglable) | 15km/h |
| Vitesse maximale de fonctionnement à pleine charge (réglable) | 13km/h |
| Spécifications de la roue avant | 28X9-15 (X2) |
| Spécification de la roue arrière | 27X10-12 |
| Couleur du véhicule | couleur personnalisée |
| Nombre de roues | 4 |
